Features:
2MP (1920*1080)@30/25fps
Ultra 265, H.265, H.264, MJPEG
120dB true WDR technology
Support 9:16 Corridor Mode
Smart IR, up to 30m (98ft) IR distance
Supports 128 G Micro SD card
IK10 vandal resistant;IP67 protection
Support PoE power supply;3-Axis
sales@veacam.com
Model |
WVCD30FB228 |
WVCD30FB240 |
|||||||
Sensor |
1/2.7", 2.0 megapixel, progressive scan, CMOS |
||||||||
Lens |
2.8mm@F2.0 |
4.0mm@F2.0 |
|||||||
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
||||
2.8 |
42 |
16.8 |
8.4 |
4.2 |
|||||
4.0 |
60 |
24 |
12 |
6 |
|||||
Angle of View (H) |
112.9° |
91.2° |
|||||||
Angle of View (V) |
59.1° |
47.9° |
|||||||
Angle of View (O) |
121.2° |
95.9° |
|||||||
Adjustment angle |
Pan: 3° ~ 360° |
Tilt: 0° ~ 68° |
Rotate: 3° ~ 360° |
||||||
Shutter |
Auto/Manual, 1 ~ 1/100000s |
||||||||
Minimum Illumination |
Colour: 0.01Lux ( F2.0, AGC ON) 0Lux with IR |
||||||||
Day/Night |
IR-cut filter with auto switch (ICR) |
||||||||
Digital noise reduction |
2D/3D DNR |
||||||||
S/N |
>52dB |
||||||||
IR Range |
Up to 30m (98ft) IR range |
||||||||
Wavelength |
850nm |
||||||||
IR On/Off Control |
Auto/Manual |
||||||||
Defog |
Digital Defog |
||||||||
WDR |
120dB |
||||||||
Video |
|||||||||
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||||||
H.264 code profile |
Baseline profile, Main profile, High profile |
||||||||
Frame Rate |
Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
||||||||
Video Bit Rate |
128 Kbps~6144 kbps |
||||||||
9:16 Corridor Mode |
Supported |
||||||||
OSD |
Up to 4 OSDs |
||||||||
Privacy Mask |
Up to 4 areas |
||||||||
ROI |
Up to 8 areas |
||||||||
Motion Detection |
Up to 4 areas |
||||||||
Image |
|||||||||
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||||||
Digital noise reduction |
2D/3D DNR |
||||||||
Smart IR |
Supported |
||||||||
Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
||||||||
Dewarping |
N/A |
||||||||
HLC |
Supported |
||||||||
BLC |
Supported |
||||||||
Smart |
|||||||||
Behavior Detection |
Cross line, intrusion(based on human body detection) |
||||||||
motion detection, tampering alarm |
|||||||||
General Function |
Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication |
||||||||
Network |
|||||||||
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL, SNMP |
||||||||
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
||||||||
Client |
Guard Viewer guardstation |
||||||||
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
||||||||
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|||||||||
Storage |
|||||||||
Edge Storage |
Micro SD, up to 128GB |
||||||||
Network Storage |
ANR,NAS(NFS) |
||||||||
Interface |
|||||||||
Network |
10/100M Base-TX Ethernet |
||||||||
Certifications |
|||||||||
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
||||||||
General |
|||||||||
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
||||||||
Power consumption: Max 5.0W |
|||||||||
Dimensions (Ø x H) |
Φ109 x 81mm (Ø4.3” x 3.2”) |
||||||||
Weight |
0.36kg (0.79lb) |
||||||||
Material |
Metal + plastic |
||||||||
Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||||
Strorage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||||
Surge Protection |
4KV |
||||||||
Ingress Protection |
IP67 |
||||||||
Vandal Resistant |
IK10 |
||||||||
Reset Button |
N/A |
