Features:
Smart PT AI Camera
2.0 Megapixel, 1080P CMOS,
Pan and Tile adjustment
Max Storage: 128GB TF card
Smart AI Features
|
WVCSDG6 |
Specifications |
|
|
Master Processor |
SOC |
T31ZL |
|
Image Sensor |
Sensor |
1/2.9" color CMOS Sensor |
|
Lens |
f=3.6mm, 2-megapixel |
|
|
PT |
H:0° ~ 355°; V:-20° ~ 90°, |
|
|
Minimum Illumination |
0.01 Lux |
|
|
Audio |
Input/Output |
Two-way voice intercom available (built-in Microphone and speaker) |
|
Audio Compressing Method |
AAC |
|
|
Video |
Video Compressing Method |
H.264/H.265 |
|
Lighting Frequency |
50Hz, 60Hz |
|
|
Image Frame Rate |
15 fps |
|
|
Maximum Image Resolution |
1920*1080P |
|
|
Light Source for Night Vision |
IRCUT double optical filter automatic switching, 850nm wavelength, IR range: 5Meters |
|
|
Network |
Wireless Network |
2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna |
|
Protocols Supported |
TCP/IP, UDP/IP, DHCP, RTMP, MUTP |
|
|
IP Address Supported |
Dynamic IP address supported |
|
|
AI |
Intelligent Features |
Human contour detection, activity zone,intelligent push, pet snapshot,Package inspection |
|
Alarm Notification |
Alarm Methods |
Alarm push by mobile APP and alarm sound |
|
Video Recording |
Recording Method |
Alarm triggered recording, and manual recording |
|
Video Storage |
Cloud storage, local Micro SD card, and mobile phone memory |
|
|
Indicator Lamps |
LED Indicator |
RGB tri-color lamp indicating the status of power/network signal/functionality |
|
Power Consumption |
Power supply |
Micro USB 5V/1A |
|
Power Consumption |
﹤5W |
|
|
Interfaces |
Power Supply |
1 Micro USB interface |
|
SD Card |
1 Micro SD card (up to 128GB supported) |
|
|
Keys |
1 reboot key and 1 on/off key |
|
|
Installation Method |
Installation Method |
Bottom 1/4 universal screw hole |
|
Environment |
Dustproof and waterproof |
IP65 |
|
Operating Environment |
-10° ~ 45°C /10% ~ 80% (no condensation) |
|
|
Storage Environment |
-20°C ~ 60° /0% ~ 90% (no condensation) |
|
|
Specifications |
Size (LxWxH) |
72mm*72mm*115.5mm(without bracket) |
|
Material + Process |
ABS+PC |
|
|
Color |
White |
|
|
Certifications |
Certificate |
CE, FCC, RoHS, |
|
CG6 Items |
Specifications |
|
|
Master Processor |
SOC |
T31ZL |
|
Image Sensor |
Sensor |
1/2.9" color CMOS Sensor |
|
Lens |
f=3.6mm, 2-megapixel |
|
|
PT |
H:0° ~ 355°; V:-20° ~ 90°, |
|
|
Minimum Illumination |
0.01 Lux |
|
|
Audio |
Input/Output |
Two-way voice intercom available (built-in Microphone and speaker) |
|
Audio Compressing Method |
AAC |
|
|
Video |
Video Compressing Method |
H.264/H.265 |
