Model

VCSK20

Pick Up Element

2.0MP CMOS

Effective Picture Elements ( H*V )

1920(H)×1080(V)

Horizontal Resolution

1080P

Video frame rate

NTSC:1920×1080@50fps；PAL:1920×1080@60fps；

Minimum Illumination

0.05Lux@（F1.2，AGC ON），0 Lux with IR

Auto Electronic Shutter

4/25s~1/45,000s

Auto Gain Control

Auto

White balance

Automatic white balance

IR Project Distance

5 Meters

IR Status

Under 10 Lux by CDS

IR Power On

CDS Auto Control

Video Output

TVI/CVI/AHD/CVBS

Auto Gain Control

Auto

Power/Current

12VDC (+/-10%)/ 350mA

Lens

2.8mm Board lens

Dimension (mm)

197*172* x 65mm

Weight (g)

850

Storage Temperature

-20~ +60℃

Operating Temperature

-10~ +50℃
