Features:
4MP (2688*1520)@ 25/20fps
Ultra 265, H.265, H.264, MJPEG
120dB true WDR technology
Support 9:16 Corridor Mode，Built-in Mic
Smart IR, up to 40m (131ft) IR distance
Supports 256 G Micro SD card，IP67 protection
Support PoE power supply，3-Axis
sales@veacam.com
|
Model |
WVCD30HB4AF |
||||||
|
Sensor |
1/3", 4.0 megapixel, progressive scan, CMOS |
||||||
|
Lens |
|||||||
|
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
||
|
2.8 |
42 |
16.8 |
8.4 |
4.2 |
|||
|
12 |
180 |
72 |
36 |
18 |
|||
|
Angle of View (H) |
102.79°~ 30.86° |
||||||
|
Angle of View (V) |
54.50°~ 17.49° |
||||||
|
Angle of View (O) |
106.94°~35.49° |
||||||
|
Adjustment angle |
Pan: 0° ~ 360° |
Tilt: 0° ~ 75° |
Rotate: 0° ~ 360° |
||||
|
Shutter |
Auto/Manual, 1 ~ 1/100000s |
||||||
|
Minimum Illumination |
Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR |
||||||
|
Day/Night |
IR-cut filter with auto switch (ICR) |
||||||
|
Digital Noise Reduction |
2D/3D DNR |
||||||
|
S/N |
>56dB |
||||||
|
IR Range |
Up to 40m (131ft) IR range |
||||||
|
Wavelength |
850nm |
||||||
|
IR On/Off Control |
Auto/Manual |
||||||
|
Defog |
Digital Defog |
||||||
|
WDR |
120dB |
||||||
|
Video |
|||||||
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||||
|
H.264 code profile |
Baseline profile, Main profile, High profile |
||||||
|
Frame Rate |
Main Stream: 4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
||||||
|
Video Bit Rate |
128 Kbps~16 Mbps |
||||||
|
9:16 Corridor Mode |
Supported |
||||||
|
OSD |
Up to 4 OSDs |
||||||
|
Privacy Mask |
Up to 4 areas |
||||||
|
ROI |
Up to 8 areas |
||||||
|
Motion Detection |
Up to 4 areas |
||||||
|
Image |
|||||||
|
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||||
|
Digital Noise Reduction |
2D/3D DNR |
||||||
|
Smart IR |
Supported |
||||||
|
Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
||||||
|
Dewarping |
N/A |
||||||
|
HLC |
Supported |
||||||
|
BLC |
Supported |
||||||
|
Audio |
|||||||
|
Audio Compression |
G.711 |
||||||
|
Suppression |
Supported |
||||||
|
Sampling Rate |
8KHZ |
||||||
|
Storage |
|||||||
|
Edge Storage |
Micro SD, up to 256GB |
||||||
|
Network Storage |
ANR, NAS(NFS) |
||||||
|
Smart |
|||||||
|
Behavior Detection |
Cross line, intrusion(based on human body detection) |
||||||
|
motion detection, tampering alarm, audio detection |
|||||||
|
General Function |
Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication |
||||||
|
Network |
|||||||
|
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS, 802.1x, SNMP |
||||||
|
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
||||||
|
Client |
Guard Viewer guardstation |
||||||
|
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
||||||
|
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|||||||
|
Interface |
|||||||
|
Network |
10M/100M Base-TX Ethernet |
||||||
|
Built-in Mic |
Supported |
||||||
|
Certifications |
|||||||
|
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
||||||
|
General |
|||||||
|
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
||||||
|
Power consumption: Max 8.0W |
|||||||
|
Dimensions (Ø x H) |
Φ129 x 110mm (Ø5.1” x 4.3”) |
||||||
|
Net Weight |
0.67kg (1.48lb) |
||||||
|
Material |
Metal |
||||||
|
Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||
|
Strorage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||
|
Surge Protection |
6KV |
||||||
|
Ingress Protection |
IP67 |
||||||
|
Reset Button |
Supported |
||||||
